Xycom 9462 - VGA Connector

Appendix C – Pinouts
C-5
VGA Connector
The VGA connector is a 15-pin connector.
AHIP4+
Pin Signal
1 RED
2 GREEN
3 BLUE
4 NC
5 ORB_GND
6 ORB_GND
7 ORB_GND
8 ORB_GND
9 NC
10 ORB_GND
11 NC
12 NC
13 HSYNC
14 VSYNC
15 NC
AHIP5+
Pin Signal
1 RED
2 GREEN
3 BLUE
4 NC
5 ORB_GND
6 ORB_GND
7 ORB_GND
8 ORB_GND
9 Fused VCC
10 ORB_GND
11 NC
12 DDCDAT
13 HSYNC
14 VSYNC
15 DDCCLK
