6.3.1 Main Voltage Terminals
The power supply is connected to the power section:
terminal L1+N (1 x 230 VAC, single-phase)
terminal L1+ L2 + L3 (3 x 400 VAC, three-phase)
HV 2.1f / 2.2f HV3.2f - 3.11f
HV 3.15e – 3.22e
Power Supply
3x 400VAC
Motor connection
Power Supply
1x230 VAC
Motor connection
Power Supply
3x400 VAC
Motor connection
