3 Technical Data
HYDROVAR Power Supply
Type Rated
output
Voltage limits
48-62 Hz
Rated
current input
line protection
max.
Maximum
connection
HV [kW] [V] [A] [A] [mm²]
2.1f 1,5 12,7 20
2.2f 2,2
1x220-240 -10% +15%
16,5 25
10
3.2f 2,2 6,3 13
3.3f 3 7.4 13
3.4f 4
3x380-460 ± 15%
9,5 16
10
3.5f 5,5 12,6 20
3.7f 7,5 16,3 25
3.11f 11
3x380-460 ± 15%
23,2 32
10
3.15e 15 31,6 40
3.18e 18,5 39 50
3.22e 22
3x380-460 -15% +10%
46,3 63
25
3.30e 30 61 80
3.37e 37 74,7 100
3.45e 45
3x380-460 -15% +10%
89,5 125
50
HYDROVAR Output to the motor
Type Rated
Output
Max. Voltage
Output
Rated Current
output
Motor connection cables
HV [kW] [V] [A] mm²
2.1f 1,5 7
2.2f 2,2
3x U
in
10
4x1,5 – 4x4
3.2f 2,2 5,7
3.3f 3 7
3.4f 4
3x U
in
9
4x1,5 – 4x4
3.5f 5,5 13,5
3.7f 7,5 17
3.11f 11
3x U
in
23
4x2,5 – 4x6
3.15e 15 30
3.18e 18,5 37
4x6 – 4x25
3.22e 22
3x U
in
43 4x10 - 4x25
3.30e 30 58 4x25 – 4x50
3.37e 37 71
3.45e 45
3x U
in
85
3x35+1x25 – 4x50
Make sure that the Hydrovar’s electrical data match those of the electric pump.
Improper combinations may cause malfunctions and fail to ensure the protection
of the electric motor.
