en - Original instructions
Genyo plus, Additional Installation, Operation and Maintenance Instructions 31
9 Technical Information
9.1 Operating data and conditions
Data
Description
Input frequency
50/60 Hz ± 2
Main supply
L - N
Nominal input voltage
110 to 230 VAC ± 10%
Maximum absorbed current AC in continuous duty S1
16 A, cosØ ≥ 0.6
Electric motor nominal power
0.37 to 2.2 kW
START pressure
0.05 to 0.7 MPa, 0.5 to 7 bar (7.3 to 102 psi)
STOP pressure
0.1 to 0.8 MPa, 1 to 8 bar (14.5 to 116 psi)
Maximum differential
0.75 MPa, 7.5 bar (109 psi)
Minimum differential
0.05 MPa, 0.5 bar (7.3 psi)
Maximum pressure PN
0.8 MPa, 8 bar (116 psi)
Fluid connection
Rp ¼”
Weight
0.4 kg (0.88 lb)
EMC (Electro Magnetic Compatibility)
See Declarations on page 33 .
Protection class
IP 55, protect the product against rain and direct sunlight
Relative air humidity, place of operation and storage
5% to 95%
Storage temperature
-25 to 65°C (-13 to 149°F)
Ambient operating temperature
0 to 50°C (32 to 122°F)
Water temperature
0 to 40°C (32 to 104°F)
9.2 Dimensions
Genyop_M0024_A_sc
Rp 1/4”
75 mm (2,95 in)
112 mm (4,4 in)
75,1 mm (2,96 in)
