Multi 3630/3620 IDS Operation
ba77045d02 03/2020 13
4.2.3 Overview of the samples of the set
The current measured values of all samples are automatically called up when
the details of a set are queried (with <MENU/ENTER> in the OxiTop set man-
agement).
After selecting a sample with <><> you can output the measurement data
of the highlighted sample to the USB interface with <PRT_> or <PRT>:
1 Set name
2 Sample name, measured value, type, OxiTop
®
-IDS measuring
heads called up/number of OxiTop
®
-IDS measuring heads in the
sample;
Check mark (
= finished) next to Sample name :
when the data of the measuring head have been transmitted to
the meter at the end of the specified Duration
Asterisk (* = Alarm diff. pressure exceeded) next to measured
value:
if the Alarm diff. pressure is exceeded in at least one OxiTop
®
-
IDS measuring head of the sample (only for Measuring mode:
Pressure p)
3 Status line (number of OxiTop
®
-IDS measuring heads that can yet
be registered)
4 <F1>/[
i
]: the graphic evaluation of the OxiTop
®
-IDS measuring
heads of the highlighted sample is displayed.
5 <F2>/[Delete] (deletes the highlighted sample)
Selecting a sample with <><> and confirming with <MENU/
ENTER> causes the overview of the OxiTop
®
-IDS measuring
heads of the highlighted sample to be displayed.
Key Explanation
<PRT_> Output of the data as a *.csv file to the USB-A interface, to a
connected USB memory device.
<PRT> Output of the data in ASCII or CSV format (setting in the system
menu) to the interface USB-A or USB-B.
The meter recognizes whether a printer or PC is connected.
A-1
4000 mg/l BOD5 1/1
A-2 357 mg/l BOD5 2/3
79 Free meas. heads
Set 190216-1
15.03.2020 08:00
Delete
i
1
2
3
4
5
