Multi 3630/3620 IDS Operation with OxiTop
®
-IDS measuring heads
ba77045e01 09/2019 27
1 Using <><> highlight a set in the OxiTop set management Set.
2 Open the details of the selected set with <MENU/ENTER>.
The measuring heads automatically call up the current data of the set.
The reading out takes approx 5 seconds per OxiTop
®
-IDS measuring
head, with many measurement data it may take longer.
3 Select a sample of the set and open the details of the selected sample
with <MENU/ENTER> or <F1>/[
i ].
 Using <MENU/ENTER>, display the individual measuring heads of
the selected sample. There you can
– view the data of the individual measuring heads that were last
stored
– Display the current measured value and make the LED of the
corresponding measuring head light up with <F1>/[
i ]
– Delete individual measuring heads from the sample as neces-
sary with <F2>/[Delete]
 Using <F1>/[
i ] display the graphic evaluation of the sample
 Using <F2>/[Delete] delete the sample
A-1 4000 mg/l BOD180 1/1
A-2 357 mg/l BOD180 2/3
79 Free measuring heads
Set name 190216-1
28.05.2019 08:00
Delete
i
