Xylem WTW OxiTop-IDS - Sample

Multi 3630/3620 IDS Operation
ba77045e01 09/2019 15
4.2.4 Overview of the OxiTop
®
-IDS measuring heads in a sample
The details of the OxiTop
®
-IDS measuring heads registered for a sample are
listed in the overview of samples in the set and can be viewed by selecting a
sample with <><> and displaying it with <MENU/ENTER>.
1 Sample name
2 Number of the OxiTop
®
-IDS measuring head (set at the OxiTop
®
-
IDS measuring head)
– Check mark ( = finished):
when the data of the measuring head have been transmitted to
the meter at the end of the specified Duration
3 Series number of the OxiTop
®
-IDS measuring head
4 Measured value
(last value transmitted by the measuring head in the specified
interval)
– Asterisk (* = Warning difference pressure exceeded):
if the Warning difference pressure in the OxiTop
®
-IDS measur-
ing head is exceeded (only for Measuring mode: Pressure p)
5 <F1>/[
i ]: the LED at the highlighted OxiTop
®
-IDS measuring head
lights up red for a short time
6 <F2>/[Delete]: deletes the highlighted OxiTop
®
-IDS measuring head
from the sample
12  020190001 123 mg/l
13 020190015 125 mg/l
21 020190123 127 mg/l
79 Free measuring heads
Sample A-1
28.05.2019 08:00
Delete
i
243
1
6
5
