XZENT xt7010 - Controls and Indicators; Button Operation

Controls and Indicators
1 POWER OFF/ VOL
Rotary encoder.
Press the encoder to turn on the unit, press and hold it to turn off.
Rotate clockwise/counterclockwise to adjust the volume.
Press to enter the audio adjust menu when the unit is on.
2 MUTE
Press the button to mute the volume, and press the button again to restore the volume.
6
1
22 21 20
2 3 4 5 6 7 8 9
10 11
12
13
14
16
17
15
19
18
Button Operation
MANUAL XT7010:Layout 1 16.11.2007 17:16 Uhr Seite 6
