Tables of Setup Menu Operations
Setup Menu no. / item Description
Selectable options
(
Options in bold are the default settings )
DISPLAY
1 TARGET LOCATION Set what to display using the smart
navigation function.
COMPASS / NUMERIC
2 COMPASS Set the compass display of the smart
navigation function.
HEADING UP / NORTH UP
3 BAND SCOPE Set the number of search channels
for the band scope function.
19ch / 39ch / 79ch
4 LAMP Set the duration time of the backlight
and keys to be lit.
KEY: OFF / 2 to 180 / CONTINUOUS
KEY 30Sec
SAVE: ON / OFF
5 LANGUAGE Switch between Japanese/English for
the menus and Setup Menu, etc.
ENGLISH / JAPANESE
6 LCD BRIGHTNESS Set the brightness level of the LCD
backlight and numeric keypad light.
LEVEL1 to LEVEL6
7 DISPLAY COLOR Set the font color of the operation
band frequency.
WHITE / BLUE / RED
8 OPENING MESSAGE Set the opening message type. OFF / DC / MESSAGE
9 SENSOR INFO Display the voltage. DC
10 SOFTWARE VERSION Display the software version. Main / Sub / DSP
TX/RX
1 MODE
1 ANTENNA ATT Switch the attenuator between ON/
OFF.
ON / OFF
2 FM DEVIATION Set the FM transmission modulation
level.
WIDE / NARROW
3 RX MODE Select the receive mode. AUTO / FM / AM
2 DIGITAL
1 DIGITAL POPUP Set the POP UP time. OFF / BAND2s / BAND4s / BAND6s /
BAND8s / BAND10s / BAND20s /
BAND30s / BAND60s / BNDCNT
2 LOCATION SERVICE Set whether or not to display your
current location in digital mode.
ON / OFF
3 STANDBY BEEP Switch the standby beep function
between ON/OFF.
ON / OFF
4 DIGITAL VW Turn the VW mode selection ON or
OFF.
OFF / ON
5 AUDIO PITCH Audio quality setting of received audio
in digital mode.
FLAT / HIGH BOOST / LOW BOOST
3 AUDIO
1 MIC GAIN Adjust the microphone gain level. LEVEL1 to LEVEL9 LEVEL5
2 MUTE Set the muting level on the non
operating band side when a signal is
received on the operating band side.
OFF / MUTE 30% / MUTE 50% /
MUTE 100%
3 RX AF DUAL Set the resumption time of radio
reception in the AF Dual mode.
Transmit and receive 1 second to
10 seconds, Fixed, or transmission 1 second
to 10 seconds.
Transmit and receive 2 seconds
4 SP SELECT Speaker operation switching settings
when connecting to an external SP/
MIC
AUTO / FIX
5 VOX VOX function setting. VOX: OFF / LOW / HIGH
DELAY: 0.5s / 1.0s / 1.5s / 2.0s / 2.5s / 3.0s
6 RECORDING Voice recode function setting. BAND: A / B / A+B
MIC: ON / OFF
