Yale Assure Lever YRL216 - Installation Step 11: Test Thumbturn Operation; Thumbturn Lock;Unlock Test

P/N YRL-PB-MNL-0017 Rev C
Part of ASSA ABLOY
12
Test Thumbturn Operation with Door Open
Outside of
Right Hand Door
Test thumbturn and both levers in locked and unlocked positions. If operation fails, check
installation beginning with Step 4 and refer to Hardware Troubleshooting.
Outside of
Right Hand Door
