Yale Assure Lock SL

13
Using Your Lock
Speaker
Press to return to
previous Settings Menu
Low Battery
Indicator
All Code Lockout Mode
Indicator
Battery Back-up
Hold a 9V battery to the
terminals in case of dead
lock batteries
Touchscreen Keypad
Press to wake keypad
or lock door
Enter Master Entry Code
and press to access
Settings Menu
Press to enter
or unlock
Inside Lock
Thumbturn for
manual locking
and unlocking
Privacy Button
Battery Cover
Inside Notification
Light
P/N YRD256-MNL-0003 Rev F
