Table 1. Display Switch Cluster – Right-Side Display Inputs (See Figure 7) (Continued)
Item
No.
Item Function
8 Rear Work Lights This button controls the rear work lights on lift trucks equipped with this option.
9 #3 Button If the lift truck is equipped with rear work lights, the #3 Button and the Rear Work Light
button will share space on the Display Switch Cluster.
When an operator or supervisor is in the main menu for entering and administering
passwords, the Rear Work Lights function is disabled and the button is enabled to enter
the number 3 for password purposes. If the lift truck is not equipped with rear work lights,
then this button functions only as Password entry #3.
10 Scroll Down This button is used for the following functions:
• Decreasing the value of a selected operating function
• Scrolling downward through a list of possible menu selections
11 #4 Button The Scroll Down and #4 Button share the same space on the Display Switch Cluster.
When an operator or supervisor is in the main menu for entering and administering
passwords, the Scroll Down function is disabled and the button is enabled to enter the
number 4 for password purposes.
