Table 1. Display Switch Cluster – Right-Side Display Inputs (See Figure 7) (Continued)
Item
No.
Item Function
4 #1 Button When an operator or supervisor is in the main menu for entering and administering
passwords, this button is used to enter the number 1 for password purposes.
If the lift truck is equipped with a Techtronix 200X Transmission, the 1st Gear Locking
function and the #1 button will share space on the Display Switch Cluster. When an
operator or supervisor is in the main menu for entering and administering passwords,
the 1st Gear Locking function is disabled and the button is enabled to enter the number
1 for password purposes. If the lift truck is not equipped with a Techtronix 200X Trans-
mission, then this button functions only as Password entry #1.
5 Front Work Lights This button controls the front work lights and the marker lights on lift trucks equipped with
this option.
6 #2 Button If the lift truck is equipped with front work lights, the #2 Button and the Front Work Light
button will share space on the Display Switch Cluster.
When an operator or supervisor are in the main menu for entering and administering
passwords, the Front Work Lights function is disabled and the button is enabled to enter
the number 2 for password purposes. If the lift truck is not equipped with Front Work
Lights, then this button functions only as Password entry #2.
7 Enter Button This button is used for menu entry, navigation, and data entry.
