Table 2. Instruments – Warning and Indicator Lights (See Figure 8) (Continued)
Item No. Item Function
10 Indicator Light
Right Turn Signal
This green indicator will blink on and off when the right turn signal is selected. Not
on at Start Check.
11 Warning Light,
Transmission Oil
Temperature
Malfunction
Indicator
CAUTION
Do not continue to operate the lift truck if the red light is ON.
The red light will illuminate when the transmission oil temperature reaches the preset
warning level.
When light illuminates, and if truck is equipped with optional powertrain protection,
truck performance will decrease. Turn truck OFF and notify service person immedi-
ately for repair. If truck is not equipped with optional powertrain protection and light
is illuminated when engine is running, turn engine OFF immediately and have truck
repaired by service technician.
Model Description
35
