Table 2. Instruments – Warning and Indicator Lights (See Figure 8) (Continued)
Item No. Item Function
12 Warning Light,
Engine Oil
Pressure
Malfunction
Indicator
CAUTION
Stop the engine immediately if the red light is ON while the engine is running.
The red light will illuminate when the system is not in the OFF state and the oil pres-
sure sensor indicates an insufficient pressure. This includes illuminating at System
Power ON until the normal operating minimum is reached. Not on at Start Check.
When light illuminates, lift truck will enter Engine Shutdown mode, if equipped with
optional powertrain protection. See Operating Procedures section for Engine Shut-
down procedures. If truck is not equipped with optional powertrain protection and
light is illuminated when engine is running, turn engine OFF immediately and have
truck repaired by service technician.
Model Description
36
