Table 3. Operator Controls (See Figure 9) (Continued)
Item
No.
Item Function
12
Direction
Control
Lever
NOTE: There is a sensor in the seat that actuates an audible buzzer. If the operator
leaves the seat with the key switch ON and the lever is not in NEUTRAL, the buzzer
will pulse ON and OFF for 10 seconds.
The Direction Control Lever for the transmission is on the left side of the Display
Switch Cluster. The Direction Control Lever is used on lift trucks without a Foot
Directional Control pedal. The Direction Control Lever has three positions that are
indicated by three green lights on left side of Display Switch Cluster (see Figure 8
and Table 2), NEUTRAL (N), and REVERSE. Move the lever to one of the direction
positions for travel. The Direction Control Lever must be in the NEUTRAL (N) posi-
tion before the engine can be started. The reverse lights will be on and, if equipped,
reverse alarm will be activated when the lever is placed in the REVERSE position.
Model Description
54
