Yamaha 1999 YZF-R6 Service Manual

4-43
CLUTCH
ENG
Order Job/Part Q’ty Remarks
1
2
Removing the clutch cover
Bottom cowing and right side cowling
Engine oil
Coolant
Therm bypass hose
Clutch cable
1
1
Remove the parts in the order listed.
Refer to “COWLINGS” in chapter 3.
Drain.
Refer to “CHANGING THE ENGINE OIL”
in chapter 3.
Drain.
Refer to “CHANGING THE COOLANT” in
chapter 3.
12 Nm (1.2 mkg)
12 Nm (1.2 mkg)
EB405000
CLUTCH
CLUTCH COVER

Yamaha 1999 YZF-R6 Specifications

General

Bore x Stroke	65.5 mm x 44.5 mm
Compression Ratio	12.4:1
Ignition	Digital TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Front Brakes	Dual 298 mm discs
Front Tire	120/60-ZR17
Rear Tire	180/55-ZR17
Wheelbase	1, 380 mm (54.3 in)
Seat Height	820 mm (32.3 in)
Engine Type	liquid-cooled, DOHC, inline 4-cylinder
Rear Suspension	Single shock
Rear Brakes	220mm disc
Fuel Capacity	17 l (4.5 US gal)
Dry Weight	169 kg
