7-62
STEERING HEAD
CHAS
CAUTION:
NOTE:
b. Remove the bearing race from the lower
bracket with a floor chisel
2
and hammer.
c. Install a new dust seal and new bearing
races.
If the bearing race is not installed properly,
the steering head pipe could be damaged.
Always replace the bearing balls and bearing
races as a set.
Whenever the steering head is disassembled,
replace the dust seal.
4. Check:
upper bracket
lower bracket
(along with the steering stem)
Bends/cracks/damage Replace.
EAS00683
INSTALLING THE STEERING HEAD
1. Lubricate:
upper bearing
lower bearing
bearing races
Recommended lubricant
Lithium soap base grease
2. Install:
bearing
bearing cover
lower ring nut
1
rubber washer
2
upper ring nut
3
lock washer
4
Refer to “CHECKING AND ADJUSTING
THE STEERING HEAD” in chapter 3.
