Yamaha 1999 YZF-R6 Service Manual

3-7
COWLINGS
CHK
ADJ
NOTE:
NOTE:
REMOVAL
1. Remove:
S rear cowling
S side cowlings
To remove the quick fastener, turn its center to
90_ with a screwdriver, then pull the fastener
out.
INSTALLATION
1. Install:
S side cowlings
S rear cowling
To install the quick fastener, push its pin so that
it protrudes from the fastener head, then insert
the fastener into the cowling and push the pin
a
in with a screwdriver. Make sure that the pin is
flush with the fastener’s head.

Yamaha 1999 YZF-R6 Specifications

General

Bore x Stroke	65.5 mm x 44.5 mm
Compression Ratio	12.4:1
Ignition	Digital TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Front Brakes	Dual 298 mm discs
Front Tire	120/60-ZR17
Rear Tire	180/55-ZR17
Wheelbase	1, 380 mm (54.3 in)
Seat Height	820 mm (32.3 in)
Engine Type	liquid-cooled, DOHC, inline 4-cylinder
Rear Suspension	Single shock
Rear Brakes	220mm disc
Fuel Capacity	17 l (4.5 US gal)
Dry Weight	169 kg
