Yamaha 1999 YZF-R6 Service Manual

22
1
3
5
7
9
2
4
8
6
24 25
2321
19 2018
16 1715
1413
11 12
10
GEN
INFO
SPEC
ENG
CARB
ELECCHAS
COOL
CHK
ADJ
TRBL
SHTG
EB004000
SYMBOLS
The following symbols are not relevant to every
vehicle.
Symbols
1
to
9
indicate the subject of each
chapter.
1
General information
2
Specifications
3
Periodic checks and adjustments
4
Engine
5
Cooling system
6
Carburetor(-s)
7
Chassis
8
Electrical system
9
Troubleshooting
Symbols
10
to
17
indicate the following.
10
Serviceable with engine mounted
11
Filling fluid
12
Lubricant
13
Special tool
14
Tightening torque
15
Wear limit, clearance
16
Engine speed
17
Electrical data
Symbols
18
to
23
in the exploded diagrams indi-
cate the types of lubricants and lubrication
points.
18
Engine oil
19
Gear oil
20
Molybdenum disulfide oil
21
Wheel bearing grease
22
Lithium soap base grease
23
Molybdenum disulfide grease
Symbols
24
to
25
in the exploded diagrams indi-
cate the following.
24
Apply locking agent (LOCTITE

)
25
Replace the part

Yamaha 1999 YZF-R6 Specifications

General

Bore x Stroke	65.5 mm x 44.5 mm
Compression Ratio	12.4:1
Ignition	Digital TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Front Brakes	Dual 298 mm discs
Front Tire	120/60-ZR17
Rear Tire	180/55-ZR17
Wheelbase	1, 380 mm (54.3 in)
Seat Height	820 mm (32.3 in)
Engine Type	liquid-cooled, DOHC, inline 4-cylinder
Rear Suspension	Single shock
Rear Brakes	220mm disc
Fuel Capacity	17 l (4.5 US gal)
Dry Weight	169 kg
