Effect 161
DME32—Owner’s Manual
Dyna Flange
The Dyna Flange component offers two-channel dynamic flanging effects.
The Dyna Flange component features two inputs and
two outputs.
The Dyna Flange control window consists of flanger controls, input level meters, out-
put level meters, and a direction (DIR) selector.
The IN meters display the input signal levels, while the OUT meters display the output
signal levels.
Parameter Range Description
SENSE 0–100 Input sensitivity
FB. GAIN –99 to +99%
Feedback gain (plus values for normal-phase feed-
back, minus values for reverse-phase feedback)
OFFSET 0–100 Delay time offset
DECAY
1
1. 6 ms–46.0 s (fs = 44.1 kHz), 5 ms–42.3 s (fs = 48 kHz)
Speed of resonant frequency changes
DIR. Up, Down
Direction of resonant frequency changes (reso-
nant frequency reacts to the input signal)
