m Preset value of the CINEMA Equalizer
L, C, R EQ
HIGH: FRQ
............
12.7 kHz
GAIN
...........................
–3 dB
FRONT, REAR EFCT EQ
HIGH: FRQ
............
12.7 kHz
GAIN
.............................
0 dB
m Frequency characteristics
The following curves show frequency characteristics when the
High-shelving equalizer (HIGH) is adjusted at the indicated values.
HIGH: FRQ
...............................
1.0 kHz
GAIN
.............................
+6 dB to –9 dB
HIGH: FRQ
...........
1.0 kHz to 12.7 kHz
GAIN
.................................
+6 dB/–9 dB
PEQ: FRQ
.............
12.7 kHz
GAIN
...........................
–4 dB
PEQ: FRQ
...............
8.0 kHz
GAIN
...........................
–3 dB
+
6
+
3
0
–
3
–
6
–
9
20 50 100 200 500 1k 2k 5k 10k 20k
PEQ
HIGH
HIGH
+
PEQ
(OVERALL)
Frequency (Hz)
GAIN (dB)
Frequency (Hz)
GAIN (dB)
Frequency (Hz)
GAIN (dB)
Frequency (Hz)
GAIN (dB)
+
6
+
3
0
–
3
–
6
–
9
20 50 100 200 500 1k 2k 5k 10k 20k
HIGH
PEQ
+
6
+
3
0
–
3
–
6
–
9
20 50 100 200 500 1k 2k 5k 10k 20k
+
6
+
3
0
–
3
–
6
–
9
20 50 100 200 500 1k 2k 5k 10k 20k
FREQ.
POINTS
1.0k
1.2k
1.6k
2.0k
2.5k
3.2k
4.0k
5.0k
5.7k
6.3k
7.1k
8.0k
9.0k
10.1k
11.3k
12.7kHz
