Yamaha DSP-AX1/RX-V1 User Manual

132
DSP-AX1/RX-V1
133
■ MECHANICAL PARTS
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
2-1-a VZ619800 SUPPORT HINGE
2-1-b VZ830500 SUPPORT MG
2-1-c VZ621800 SHAFT AA
2-1-d VZ621900 MAGNET
* 2-1-e V4321400 PANEL, LID BL
* 2-1-e V4321600 PANEL, LID GD
* 2-1-f V4324400 PLATE, L RX-V1 BL (UCA)
* 2-1-f V4324700 PLATE, L RX-V1 GD (UCA)
* 2-1-f V4481600 PLATE, L DSP-AX1 BL (RBGT)
* 2-1-f V4481800 PLATE, L DSP-AX1 GD (RBGT)
* 2-1-g V4324800 PLATE, SP RX-V1 BL (UCA)
* 2-1-g V4325000 PLATE, SP RX-V1 GD (UCA)
* 2-1-g V4516800 PLATE, SP DSP-AX1 BL (RBGT)
* 2-1-g V4517000 PLATE, SP DSP-AX1 GD (RBGT)
* 2-1-h V4328200 CASE, SUB PANEL BL
* 2-1-h V4328400 CASE, SUB PANEL GD
2-1-i V2048500 CUSHION, LID GD
2-1-i VT062900 CUSHION BL
2-1-j VZ875000 SPACER MG
2-1-k VH625500 DAMPER
* 2-1-l V4481100 BUTTON, TU RX-V1 BL (UCA)
* 2-1-l V4481300 BUTTON, TU RX-V1 GD (UCA)
* 2-1-m V4329400 HINGE, R BL
* 2-1-m V4329600 HINGE, R GD
2-1-n V0047400 HINDGE GD
2-1-n VZ629400 HINDGE BL
* 2-1-o V5095100 DAMPER, GEAR 058E-L
2-1-p ED330066 BIND HEAD SCREW 3x6 FCRM3-BL
2-1-q EK930010 PW HEAD B-TITE SCREW 3x8-8 FCRM3-BL
2-1-r VG893800 BIND HEAD P-TITE SCREW 2x6 ZMC2-BL
2-1-s VE529700 PW HEAD B-TITE SCREW 3x6-8 FCRM3-BL
2-1-t V3217600 PLATE, GROUND
2-1-u EP600190 BIND HEAD B-TITE SCREW 3x8 ZMC2-BL RX-V1 (UCA)
2- 8 MF116250 FLEXIBLE FLAT CABLE 16P 250mm
2- 9 MF117200 FLEXIBLE FLAT CABLE 17P 200mm
* 2-11 V4318400 SUB CHASSIS
* 2-12 V4481900 SUPPORT, PJ PJ
* 2-13 V4328700 BUTTON CASE UPPER BL
* 2-13 V4328900 BUTTON CASE UPPER GD
* 2-15 V4323100 ESCUTCHEON, VOL BL
* 2-15 V4323300 ESCUTCHEON, VOL GD
2-16 VZ625900 ESCUTCHEON, SEL BL
2-16 VZ756800 ESCUTCHEON, SEL GD
2-17 V2467300 BUTTON 3/8 BL
2-17 V2467500 BUTTON 3/8 GD
* 2-18 V5181000 SUPPORT ENC
* 2-19 V5181200 SUPPORT
2-20 CB605620 PLASTIC RIVET No.1781
2-21 EP600190 BIND HEAD B-TITE SCREW 3x8 ZMC2-BL
2-22 VR145000 BIND HEAD BONDING TAP. SCREW 3x12 MFZN2-BL
2-23 VN413300 BIND HEAD BONDING B-T. SCREW 3x8 MFZN2-BL
2-24 ED330066 BIND HEAD SCREW 3x6 FCRM3-BL
* 3- 1 V4325100 HEAT SINK ASS’Y, L 52BS300-L130ASSY
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
* 3- 1 V4766700 HEAT SINK ASS’Y, R 52BS300-L130ASSY
Z # 3- 2 V4863600 PAIR TRANSISTOR 2SA1943/C5200 O,R Q517,521,525
Z # 3- 2 V4863600 PAIR TRANSISTOR 2SA1943/C5200 O,R ,563,566,570
# 3- 3A iX615750 TRANSISTOR 2SA1694 O,P,Y Q575A,Q580A
# 3- 3C iX615760 TRANSISTOR 2SC4467 O,P,Y Q575C,Q580C
# 3- 4 VC398100 TRANSISTOR 2SC1846 S Q508,511,514
# 3- 4 VC398100 TRANSISTOR 2SC1846 S ,552,555,558
Z # 3- 4 VC398100 TRANSISTOR 2SC1846 S ,560,561
3- 5 VK196000 SHEET 22x29
3- 6 VK195900 SHEET 19x24
3- 9 VK173200 SCREW, TRANSISTOR 3x15 SP FCM3
3-10 VK697600 BIND HEAD B-TITE SCREW 3x10 SP ZMC2-Y
3-13 VU195800 DAMPER, FIN
* 3-14 V5120300 SUPPORT, PCB PCB
* 6- 1 V3316600 DC BRUSHLESS FAN 2410ML-05W-B40-T14
6- 2 VZ619400 SUPPORT FAN
6- 3 VV220300 BIND HEAD B-TITE SCREW 3x30 MFZN2-BL
* 7-11 V4326200 HEAT SINK, L
7-12 EK930010 PW HEAD B-TITE SCREW 3x8-8 FCRM3-BL
7-13 VK697600 BIND HEAD B-TITE SCREW 3x10 SP ZMC2-Y
* 11 V5001000 P.C.B. ASS’Y MAIN (U)
* 11 V5001100 P.C.B. ASS’Y MAIN (C)
* 11 V5001200 P.C.B. ASS’Y MAIN (RT)
* 11 V5001300 P.C.B. ASS’Y MAIN (A)
* 11 V5001400 P.C.B. ASS’Y MAIN (BG)
* 12 V5001600 P.C.B. ASS’Y VIDEO (UC)
* 12 V5001700 P.C.B. ASS’Y VIDEO (RT)
* 12 V5001800 P.C.B. ASS’Y VIDEO (A)
* 12 V5001900 P.C.B. ASS’Y VIDEO (BG)
* 13 V5002100 P.C.B. ASS’Y SUB TRANS. (U)
* 13 V5002200 P.C.B. ASS’Y SUB TRANS. (C)
* 13 V5002300 P.C.B. ASS’Y SUB TRANS. (RT)
* 13 V5002400 P.C.B. ASS’Y SUB TRANS. (A)
* 13 V5003500 P.C.B. ASS’Y SUB TRANS. (B)
* 13 V5003600 P.C.B. ASS’Y SUB TRANS. (G)
* 14 V5002600 P.C.B. ASS’Y FUNCTION (UC)
* 14 V5002700 P.C.B. ASS’Y FUNCTION (RT)
* 14 V5002800 P.C.B. ASS’Y FUNCTION (A)
* 14 V5002900 P.C.B. ASS’Y FUNCTION (BG)
* 15 V5003000 P.C.B. ASS’Y DSP (RBGT)
* 15 V5003100 P.C.B. ASS’Y DSP (UA)
* 15 V5003200 P.C.B. ASS’Y DSP (C)
16 V2518600 P.C.B. ASS’Y TUNER/TU-01 RX-V1 (UC)
16 V2518800 P.C.B. ASS’Y TUNER/TU-01 RX-V1 (A)
16 V2519300 P.C.B. ASS’Y TUNER/TU-01,CHIP RX-V1 (UC)
16 V2519500 P.C.B. ASS’Y TUNER/TU-01,CHIP RX-V1 (A)
Z * 21 XW967A00 POWER TRANSFORMER (U)
Z * 21 XW968A00 POWER TRANSFORMER (C)
Z * 21 XW969A00 POWER TRANSFORMER (RT)
Z * 21 XW970A00 POWER TRANSFORMER (A)
Z * 21 XW971A00 POWER TRANSFORMER (BG)
Z 21- 4 Vi449800 VOLTAGE SELECTOR ESE-37284-F (RT)
Z 21- 5 VZ855600 SLIDE SWITCH SDKGA4 (URABGT)
