14.SUM/VER/PORT
PORT: 00000000
00000000
Tuner mode 0 (Caution 1)
Tuner mode 1 (Caution 1)
Model type: DSP-AX1 (1) / RX-V1 (0)
ZONE with (1) / without (0)
VIDEO switch: PAL (1) / NTSC (0)
VIDEO format: PAL (1) / NTSC (0)
Head phone: Unconnected (1) / connected (0)
Tuner: Not stereo (1) / stereo (0)
Port to check functions of the main microprocessor
The alphabet of the compatible version represents the communication format compat-
ibility between the main and sub microprocessors. If the alphabet representing the com-
munication format compatibility agrees, the microprocessors are interchangeable. If
the alphabet is different, the replacement microprocessor will fail to function properly.
14.SUM/VER/PORT
M:G38DB/ S:E42D
Software version/compatible version/RS-232C version of main microprocessor
Software version and compatible version of sub-microprocessor
M : G 3 8 D B
Software control version (3 fig-
ures of alphabet and numbers)
Tuner mode 0 Tuner mode 1 Tuner frequency
0 0 AM : 531-1611kHz/9kHz FM : 76.0-90.0MHz/100kHz
0 1 AM : 531-1611kHz/9kHz FM : 87.5-108.0MHz/50kHz
1 0 AM : 530-1710kHz/10kHz FM : 87.5-107.9MHz/200kHz
1 1 DSP-AX1
(Caution 1)
S : E 4 2 D
Software control version (3
figures of alphabet and num-
bers)
Compatible version of micro-
processor (1 alphabet)
Compatible version of mi-
croprocessor (1 alphabet)
RS-232C communi-
cation specification
version (1 alphabet)
Main microprocessor Sub-microprocessor
32
Port to check functions of the REC OUT
14.SUM/VER/PORT
REC-OUT:0000
bit 3 2 1 0
0000
REC OUT bit
3210
PHONO 0111
CD 0110
TUNER 0100
TAPE 0101
MD 0001
DVD 0000
SOURCE 0010
LD 0011
D-TV 1011
CBL/SAT 1010
VCR1 1000
VCR2 1001
VCR3 1101
V-AUX 1100
