DSP-AX1/RX-V1
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
Z * 22 V5069600 POWER CORD ASS’Y (UC)
Z 22 VP418300 POWER CORD ASS’Y (A)
Z 22 VS759300 POWER CORD ASS’Y (G)
Z 22 VU411300 POWER CORD ASS’Y (B)
Z 22 VZ542500 POWER CORD ASS’Y (RT)
23 VN158600 CORD STOPPER No.2104 (RABGT)
23 VQ583400 CORD STOPPER No.2272 (UC)
24 CB502030 BINDING TIE S-75B
31 MF108080 FLEXIBLE FLAT CABLE 8P 80mm
32 MF111400 FLEXIBLE FLAT CABLE 11P 400mm
33 MF116060 FLEXIBLE FLAT CABLE 16P 60mm
34 MF116250 FLEXIBLE FLAT CABLE 16P 250mm
36 MF127350 FLEXIBLE FLAT CABLE 27P 350mm
* 41 V4868500 CONNECTOR, FLAT CABLE 13P 450mm RX-V1 (UCA)
50 CB069250 BINDING TIE BK-1
* 71 V4318100 TOP COVER BL
* 71 V4318300 TOP COVER GD
73 VZ618000 FRAME L
74 VU120700 FRAME, L/SF
* 75 V4318600 FRAME R/UPPER
* 76 V4318500 FRAME R/LOWER
* 77 V4600900 FRAME, CENTER
* 78 V4320400 SUPPORT, A SUB
* 79 V4318800 FRAME SL
* 81 V4803700 BOTTOM COVER
* 82 V4318900 FRAME CF
* 84 V4319100 REAR PANEL (U)
* 84 V4319200 REAR PANEL (C)
* 84 V4319400 REAR PANEL (A)
* 84 V4563300 REAR PANEL (RT)
* 84 V4563500 REAR PANEL (G)
* 84 V4563600 REAR PANEL (B)
86 VZ764400 SUPPORT CMCN
* 87 V4847300 SHIELD CASE RX-V1 (UCA)
* 89 V4318700 SHIELD CASE
* 90 V4320200 SUPPORT I/PCB
91 VT999700 SUPPORT R/FR
* 93 V4320300 SUPPORT S/PCB
* 95 V4847400 SUPPORT C/PCB
* 96 V4319700 FRAME C/UP
* 97 V4949800 SUPPORT F/PCB
* 98 V4320100 SUPPORT, SIDE AA
* 100 V4321000 FRONT PANEL RX-V1 BL (UCA)
* 100 V4321200 FRONT PANEL RX-V1 GD (UCA)
* 100 V4515100 FRONT PANEL DSP-AX1 BL (RBGT)
* 100 V4515300 FRONT PANEL DSP-AX1 GD (RBGT)
* 101 V4322200 KNOB, D45 BL
* 101 V4322500 KNOB, D45 GD
* 102 V5541400 KNOB GD
* 102 V5541300 KNOB BL
105 VS757200 KNOB D12P BL
105 VZ891300 KNOB D12P GD
106 VT275100 KNOB D12R BL
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
106 VZ891400 KNOB D12R GD
* 108 V4329700 WINDOW PANEL, LID
* 109 V4329300 PLATE SIDE/H190 CB
* 110 V4565700 PLATE CB
111 V0042500 LEG D60xH21 GD
111 VS025000 LEG D60xH21 BL
* 112 V5126500 SHIELD PLATE TU RX-V1 (UCA)
* 113 V5118300 SPACER
114 VZ822300 CUSHION, FAN
116 VZ764800 DAMPER BLACK
117 VK492200 DAMPER A
118 VE222600 CUSHION
119 VK706800 DAMPER TOP
* 120 V4867300 PLATE/FUNC
123 CB605620 PLASTIC RIVET No.1781
* 129 V5177100 PLATE/DSP
* 130 V5177200 PLATE/HEAT
* 140 V4321800 PANEL, SIDE BL
* 140 V4322000 PANEL, SIDE GD
* 141 V4563800 SIDE PANEL BL
* 141 V4564000 SIDE PANEL GD
* 144 V4656000 FLAT FILLISTER HEAD SCREW 4x12-10 MFZN2-BL BL
* 144 V4656200 FLAT FILLISTER HEAD SCREW 4x12-10 MFNI33 GD
* 145 V4656300 SPECIAL SCREW 4-7 MFZN2-BL BL
* 145 V4656500 SPECIAL SCREW 4-7 MFNI33 GD
152 VN413300 BIND HEAD BONDING B-T. SCREW 3x8 MFZN2-BL
155 EP600190 BIND HEAD B-TITE SCREW 3x8 ZMC2-BL
156 ED330066 BIND HEAD SCREW 3x6 FCRM3-BL (R)
157 EP600530 BIND HEAD S-TITE SCREW 3x8 ZMC2-BL (C)
158 EK930010 PW HEAD B-TITE SCREW 3x8-8 FCRM3-BL
159 VK625000 CUP S-TITE SCREW 5x10-12 ZMC2-Y
160 VK697600 BIND HEAD B-TITE SCREW 3x10 SP ZMC2-Y
161 EP600790 FLAT HEAD B-TITE SCREW 3x8 MFZN2-BL
164 AA627310 GROUND TERMINAL
165 EV265560 PLAIN WASHER 3.6x10x0.8 FNM3-3G
167 VY731200 BONDING HEAD TAPPING SCREW 3x10 MFNI33
169 EX601850 SPECIAL SCREW S-TITE 4x8-10 FCRM3-BL BL
169 VZ893000 DECORATED SCREW S-TIGHT 4x8-10 MFNI-33 GD
170 EP600220 BIND HEAD B-TITE SCREW 3x10 ZMC2-Y
* 171 V3768900 SCREW, LOCK 17L-003C41
* ACCESSORIES
* 200 V4565600 REMOTE CONTROL TRANSMITTER RAV220
200-1 AAX12830 LID 103RRC-170-01R SMK
200-2 SLIDE COVER 103RRC-171-01R SMK
VG850700 ANTENNA, FM 1.4m RX-V1 (UCA)
VQ307400 AM LOOP ANTENNA 81-653-645-110 RX-V1 (UCA)
VT948000 ANTENNA ADAPTER (UC)
BATTERY(ALKALINE DRY) 1.5V LR6(3S)AG
