30
YSS FULL BIT
• The signal is output in digital full bit without including
the head margin. The SWFR signal is output but not in
digital full bit.
Reference data
INPUT: DVD ANALOG
SWFR: 50Hz, Others: 1kHz
YSS FULL BIT F
• The front CH signal is output in digital full bit at the main
CH.
Reference data
INPUT: DVD ANALOG
SWFR: 50Hz, Others: 1kHz
YSSFULLBIT
 


YSSFULLBITF
 

Input level Volume
SPEAKER OUTPUT (1kHz) SUBWOOFER
MAIN L/R CENTER REAR CENTER RL/RR OUTPUT (50Hz)
Both ch, -20 dBm -10 dB +15.5 dBm +14.4 dBm +14.9 dBm +14.9 dBm +1.8 dBm
Input level Volume
SPEAKER OUTPUT (1kHz) SUBWOOFER
MAIN L/R CENTER REAR CENTER RL/RR OUTPUT (50Hz)
Both ch, -20 dBm -10 dB +15.2 dBm - ∞ - ∞ - ∞ - ∞
CS49329
( Digital Audio Data / PCM )
RC/- C/LFE LS/RS L/R
CS L/R
A/D
DIR
Main DSP Sub DSP
AD or CS L/R
L/R
LS/RS
C/LFE
C/SW
-/RC
L/R
Virtual or HP
L/R
YSS L/R
CS L/R
C(L)
LFE
(R)
L/R
RC(R)
FL/FR
(L/R)
RL/RR
(L/R)
Sp Config
DIR L/R
YSS L/R
FL/FR
Digital
Analog
RL/RR
DSP THROUGH ~
YSS (Analog)
(Shaded items not used in this example)
