RX-V740/RX-V740RDS/DSP-AX740
RX-V640/RX-V640RDS/HTR-5660/DSP-AX640/DSP-AX640SE
29
RX-V740/RX-V740RDS/DSP-AX740
RX-V640/RX-V640RDS/HTR-5660/DSP-AX640/DSP-AX640SE
YSS Front 0dB
• The front CH signal including the head margin is output
at the main CH.
Head margin:
Main L/R: 0dBFS, Center: -6dBFS,
RL/RR: -12dBFS, SWFR: Add L/R signal at -20dBFS.
Reference data
INPUT: DVD ANALOG
SWFR: 50Hz, Others: 1kHz
YSSFront0dB
• Details of DIAG menu
With full-bit output specified in some modes, it is possible
to execute 0dBFS output without head margin in each
channel.
1. DSP THROUGH
Main DSP of YSS938 is selected for MAIN L/R output.
ANALOG BYPASS
• The signal for L/R is output as it is without passing
through the DSP section.
Reference data
INPUT: DVD ANALOG
SWFR: 50Hz, Others: 1kHz
●ダイアグメニュー詳細
1. DSPTHROUGH
ANALOGBYPASS
Input level Volume
SPEAKER OUTPUT (1kHz) SUBWOOFER
MAIN L/R CENTER
REAR CENTER
RL/RR OUTPUT (50Hz)
Both ch, -20 dBm -10 dB +15.9 dBm - ∞ - ∞ - ∞ - ∞
YSS 0dB
• The signal is output including the head margin.
Head margin:
Main L/R: 0dBFS, Center: -6dBFS,
Rear Center: -6dBFS, RL/RR: -12dBFS,
SWFR: Add L/R signal at -20dBFS.
Reference data
INPUT: DVD ANALOG
SWFR: 50Hz, Others: 1kHz
YSS0dB
Input level Volume
SPEAKER OUTPUT (1kHz) SUBWOOFER
MAIN L/R CENTER
REAR CENTER
RL/RR OUTPUT (50Hz)
Both ch, -20 dBm -10 dB +15.5 dBm +14.4 dBm +14.9 dBm +14.9 dBm +1.8 dBm
Input level Volume
SPEAKER OUTPUT (1kHz) SUBWOOFER
MAIN L/R CENTER
REAR CENTER
RL/RR OUTPUT (50Hz)
Both ch, -20 dBm -10 dB +15.2 dBm - ∞ - ∞ - ∞ - ∞
