Yamaha HTR-5830 Service Manual

RX-V357/HTR-5830
45
A
1
2
3
4
5
6
7
BCDEFGH I J
VRA
PSW
CKFD
CEFD
ADKEY0
VP
+5M
VRB
REM1
/BLK
DTFD
ADKEY1
+5MS
MG
DSP
AC4
NC
AC4
FUNCTION (4)
E
+5M
PSW
FUNCTION (5)
FUNCTION (2) P. C. B. (Side A)
EON FREQ/TEXT
START MODE
TUNING MODE
AUTO/MAN'L MONO
MEMORY
MAN'L/AUTO FM
6CH INPUT
INPUT
SPEAKERS
A/B/OFF
TONE
CONTROL
-
STEREO
EFFECT
PRESET/TUNING
EDIT
+
PROGRAM
INPUT MODE
FM/AM
A/B/C/D/E
NEXT
-+
VOLUME
PTYSEEK
BASS/TREBLE
PRESET/TUNING
SET MENU
FUNCTION (2) P. C. B. (Side B) Lead Free Solder Used
164
32
16
17
49
48
33
Ref. no. Location
D551 H5
D552 H5
IC551 F5
Q551 E5
Q552 F5
Q553 G5
Q554 G5
Q555 G5
Q556 F5
• Semiconductor Location
CB653
CB671
CB804
B, G, E models only
■ PRINTEDCIRCUITBOARD(Foilside)

Yamaha HTR-5830 Specifications

General

Audio Channels	5.1
Frequency Response	10 Hz - 100 kHz
Component Video Inputs	2
Composite Video Inputs	4
Signal-To-Noise Ratio	100 dB
Input Sensitivity	200 mV
Built-in Decoders	Dolby Digital, DTS
Surround Sound Effects	Yes
Tuner Bands	AM/FM
Preset Station Qty	40
Surround Sound	Yes
S-Video Inputs/Outputs	2 inputs / 1 output
Digital Audio Inputs	2 (optical, coaxial)
Total Harmonic Distortion	0.06 %
Input Impedance	47 kΩ
Audio D/A Converter	24-bit/192 kHz
Tuning Range	FM: 87.5 - 108 MHz, AM: 530 - 1710 kHz
Width	17.1 in
Power Output	100 W
Connector Type	RCA
