Yamaha Installation Series Application Guide

Application Guide for
Yamaha Installation Series Speakers
21
• IF2112/64 used for DJ booth monitor to provide high SPL low spill to adjacent dance floor
• Family sound is essential in such an application using different loudspeaker models in close
proximity.
System Diagram
- Speaker Processing Component
1 x DME64N
2 x MY8-ADDA96 8-channel Analog I/O cards
- Client’s user control
1 x ICP1 intelligent remote panels (Bar area)
1 x CP1SF (DJ booth volume)
- Main Dance floor
4 x IF2115/95
1 x IS1218 subwoofer
3 x PC9501N amplifiers
4 x OmniMount 120.0 for IF2115/95
- Dance floor overspill
4 x IF2112/95
1 x IS1218 subwoofer
3 x PC9501N amplifiers
4 x OmniMount 120.0 for IF2112/95
- DJ Booth monitors
2 x IF2112/64
1 x PC9501N amplifier
4 x OmniMount 120.0 for IF2115/64
- Raised seating area & Dining tables
4 x IF2108
2 x IS1215 subwoofer
1 x PC3301N amplifier
1 x PC9501N amplifier
4 x U2108 U brackets for IF2108
- Bar
4 x IF2108
1 x PC4801N amplifier
4 x IF2108
1 x IS1215
1 x PC3301N amplifier
4 x U2108 U brackets for IF2108
- Chill out area
4 x IF2108
1 x PC3301N amplifier
4 x U2108 U brackets for IF2108
