Yamaha Installation Series Application Guide

Application Guide for
Yamaha Installation Series Speakers
29
Connector Pinout Guide
3-way Full-Range (bi-amp/tri-amp selectable)
IF3115/64/95
Connectors: 1x Neutrik NL8 Speakon,
1x Neutrik NL4 Speakon and 1x Terminal
strips, wired in parallel
2 -Way Mid-Highs (passive/bi-amp selectable)
IH2000
Connectors: 1x Neutrik Speakon
and 1x Terminal strips, wired in parallel
12”/15” LF 2-Way Full-Range (passive/bi-amp selectable)
IF2115(M)/64/95/99,
IF2112(M)/64/95/99
Connectors: 1x Neutrik Speakon
and 1x Terminal strips, wired in parallel
12”/15” LF 2-Way Full-Range with AS Horn (passive/bi-amp selectable)
IF2115/AS, IF2112/AS
Connectors: 2x Neutrik Speakon
and 1x Terminal strips, wired in parallel
1x8” / 2x8” LF 2-Way Full-Range
IF2108, IF2208
Connectors: 2x Neutrik Speakon
and 1x Terminal strips, wired in parallel
2x5” LF 2-Way Full-Range
IF2205
Connectors: 1x Terminal strips
IS and IL Single-Driver Models
IS1118, IL1115
Connectors: 1x Neutrik Speakon
and 1x Terminal strips, wired in parallel
IS 2x15”/2x18” Dual-Driver Subwoofers (parallel/discrete selectable)
IS1215, IS1218
Connectors: 1x Neutrik Speakon
and 1x Terminal strips, wired in parallel
NL8 NL4 Bi-Amp Bi-Amp
1+/1- 1+/1- Low Low
2+/2- 2+/2- Mid-High Mid
3+/3- - (Through) High
4+/4- - n/c n/c
NL4 Passive Bi-Amp
1+/1- Full-Range Mid
2+/2- n/c High
NL4 Passive Bi-Amp
1+/1- Full-Range LF
2+/2- n/c HF
NL4 Passive Bi-Amp
1+/1- Full-Range LF
2+/2- (Through) HF
NL4 Passive
1+/1- Full-Range
2+/2- n/c
NL4 Passive
1+/1- LF
2+/2- n/c
NL4 Parallel Discrete
1+/1- LF1 and LF2 LF1
2+/2- n/c LF2
