Yamaha Installation Series Application Guide

Application Guide for
Yamaha Installation Series Speakers
6
Small Installation: Left/Right Cluster + Mono Sub
This small installation example represents a typical Left/Right Cluster and Mono Sub
application.
Applications
- Small Hall
- Small Church
- Small Live Venue
- Meeting Room
- School
Speaker Layout
Speaker System Overview
• IF2112/AS for Left/Right cluster + IS1118 Sub system is a good choice for small venue for not
only speech but also speech + music systems.
• Rotatable Asymmetric CD horn can provide the narrow dispersion for far field and the wide
dispersion for near field, allowing the speaker to be installed in either vertical or horizontal
orientation.
• IS1118 Subwoofer allows for extended low frequency bandwidth to meet music applications.
• Switchable between bi-amp or passive mode for IF2112/AS.
