Yamaha Installation Series Application Guide

Application Guide for
Yamaha Installation Series Speakers
35
3 -Way Full-Range Speaker
LF MF(Tri-Amp) / MF+HF(Bi-AMP) HF (Tri-Amp)
Rcmd Pwr 700W – 1400W 125W -250W 110W – 220W
(A) Amp T5n 1ch
PC9501N 1ch
XP7000 1ch
PC2001N 1ch
XP2500 1ch
XP1000 1ch
PC2001N 1ch for 2(Parallel)
IF3115
(B) Amp T3n 1ch
PC6501N 1ch
XP7000 1ch
XP7000 1ch
PC9501N 1ch for 2(Parallel)
XM4080 1ch
XP1000 1ch for 2(Parallel)
Rcmd Pwr n/a 125W -250W 110W – 220W
(A) Amp n/a PC2001N 1ch
XP2500 1ch
XP1000 1ch
PC2001N 1ch for 2(Parallel)
IH2000
(B) Amp n/a XP7000 1ch
PC9501N 1ch for 2(Parallel)
XM4080 1ch
XP1000 1ch for 2(Parallel)
Rcmd Pwr 700W – 1400W n/a n/a
(A) Amp T5n 1ch
PC9501N 1ch
XP7000 1ch
n/a n/a
IL1115
(B) Amp T3n 1ch
PC6501N 1ch
XP7000 1ch
n/a n/a
Subwoofer
Discrete (Single for IS1118) Parallel
Rcmd Pwr 700W x 2 – 1400W x 2 1400W – 2800W
(A) Amp T5n 2ch
PC9501N 2ch
T5n 1ch
PC9501N 1ch
IS1215
(B) Amp T3n 2ch
PC6501N 2ch
XP7000 2ch
T3n 1ch
PC6501N 1ch
XP7000 1ch
Rcmd Pwr 700W – 1400W n/a
(A) Amp T5n 1ch
PC9501N 1ch
n/a
IS1118
(B) Amp T3n 1ch
PC6501N 1ch
XP7000 1ch
n/a
Rcmd Pwr 700W x 2 – 1400W x 2 1400W – 2800W
(A) Amp T5n 2ch
PC9501N 2ch
T5n 1ch
PC9501N 1ch
IS1218
(B) Amp T3n 2ch
PC6501N 2ch
XP7000 2ch
T3n 1ch
PC6501N 1ch
XP7000 1ch
