Yamaha Installation Series Application Guide

Application Guide for
Yamaha Installation Series Speakers
38
26dB 8dBu
-16dBFs for +24dB output level
-10dBFs for +18dB output level
-7dBFs for +15dB output level
n/a n/a
IF2205
32dB 2dBu
-22dBFs for +24dB output level
-16dBFs for +18dB output level
-13dBFs for +15dB output level
n/a n/a
3 -Way Full-Range Speaker
LF MF(Tri-Amp) / MF+HF(Bi-AMP) HF (Tri-Amp)
26dB 16dBu
-8dBFs for +24dB output level
-2dBFs for +18dB output level
0dBFs for +15dB output level
9dBu
-15dBFs for +24dB output level
-9dBFs for +18dB output level
-6dBFs for +15dB output level
8dBu
-16dBFs for +24dB output level
-10dBFs for +18dB output level
-7dBFs for +15dB output level
IF3115
32dB 10dBu
-14dBFs for +24dB output level
-8dBFs for +18dB output level
-5dBFs for +15dB output level
3dBu
-21dBFs for +24dB output level
-15dBFs for +18dB output level
-12dBFs for +15dB output level
2dBu
-22dBFs for +24dB output level
-16dBFs for +18dB output level
-13dBFs for +15dB output level
26dB n/a 9dBu
-15dBFs for +24dB output level
-9dBFs for +18dB output level
-6dBFs for +15dB output level
8dBu
-16dBFs for +24dB output level
-10dBFs for +18dB output level
-7dBFs for +15dB output level
IH2000
32dB n/a 3dBu
-21dBFs for +24dB output level
-15dBFs for +18dB output level
-12dBFs for +15dB output level
2dBu
-22dBFs for +24dB output level
-16dBFs for +18dB output level
-13dBFs for +15dB output level
26dB 16dBu
-8dBFs for +24dB output level
-2dBFs for +18dB output level
0dBFs for +15dB output level
n/a n/a
IL1115
32dB 10dBu
-14dBFs for +24dB output level
-8dBFs for +18dB output level
-5dBFs for +15dB output level
n/a n/a
