Yamaha MW10 Service Manual

4
MW10
Input Connector Gain Input Appropriate Sensitivity* Nominal Max. Before Connector
Impedance Impedance Level Clipping Specifications
-60 -72 dBu -60 dBu -40 dBu
MIC INPUT 3 k ohms 50-600 ohms mic (0.195 mV) (0.775 mV) (7.75 mV) XLR-3-31 type
(CH 1, 2) -16 -28 dBu -16 dBu +4 dBu (balanced)
(30.8 mV) (123 mV) (1.23 V)
-34 -46 dBu -34 dBu -14 dBu Phone jack (TRS)
LINE INPUT 10 k ohms 600 ohms line (3.88 mV) (15.5 mV) (155 mV) (balanced [T: hot;
(CH 1, 2) +10 -2 dBu +10 dBu +30 dBu R: cold;
(0.615 V) (2.45 V) (24.5 V) S: ground])
ST CH MIC INPUT -60 -72 dBu -60 dBu -40 dBu
(CH3(L)/CH4(R), 3 k ohms 50-600 ohms mic (0.195 mV) (0.775 mV) (7.75 mV) XLR-3-31 type
CH5(L)/CH6(R)) -16 -28 dBu -16 dBu -10 dBu (balanced)
(30.8 mV) (123 mV) (245 mV)
ST CH LINE INPUT -34 -46 dBu -34 dBu -14 dBu
(CH3(L)/CH4(R), 10 k ohms 600 ohms line (3.88 mV) (15.5 mV) (155 mV) Phone jack
CH5(L)/CH6(R)) +10 -2 dBu +10 dBu +30 dBu (unbalanced)
(0.615 V) (2.45 V) (24.5 V)
ST CH INPUT -22 dBu -10 dBu +10 dBu Phone jack
(CH7(L)/CH8(R), 10 k ohms 600 ohms line (61.5 mV) (245 mV) (2.45 V) (unbalanced);
(CH9(L)/CH10(R)) RCA pin jack
Phone jack (TRS)
CH INSERT IN 10 k ohms 600 ohms line -12 dBu 0 dBu +20 dBu (unbalanced
(CH 1, 2) (195 mV) (0.775 V) (7.75 V) [T: out; R: in;
S: ground])
RETURN (L, R) 10 k ohms 600 ohms line -8 dBu +4 dBu +24 dBu Phone jack
(308 mV) (1.23 V) (12.3 V) (unbalanced)
2TR IN (L, R) 10 k ohms 600 ohms line -22 dBV -10 dBV +10 dBV RCA pin jack
(79.4 mV) (316 mV) (3.16 V)
Where 0 dBu=0.775 Vrms and 0 dBV=1 Vrms
* Input sensitivity: the lowest level that will produce an output of +4 dBu (1.23V) or the nominal output level when the unit is set to maximum gain.
(All level controls are maximum position.)
■ Analog Input Specifications
Output Connectors Output Impedance Appropriate Nominal Level Max. Before Connector Specifications
Impedance Clipping
Phone jack (TRS)
ST OUT (L, R) 150 ohms 10 k ohms line +4 dBu (1.23 V) +20 dBu (7.75 V) (balanced [T: hot; R: cold;
S: ground])
Phone jack (TRS)
AUX SEND (1, 2) 150 ohms 10 k ohms line +4 dBu (1.23 V) +20 dBu (7.75 V) (impedance balanced
[T: hot; R: cold; S: ground])
CH INSERT OUT Phone jack (TRS)
(CH 1, 2) 150 ohms 10 k ohms line 0 dBu (0.775 V) +20 dBu (7.75 V) (unbalanced [T: out; R: in;
S: ground])
REC OUT (L, R) 600 ohms 10 k ohms line -10 dBV (316 mV) +10 dBV (3.16 V) RCA pin jack
Phone jack (TRS)
C-R OUT (L, R) 150 ohms 10 k ohms line +4 dBu (1.23 V) +20 dBu (7.75 V) (impedance balanced
[T: hot; R: cold; S: ground])
PHONES 100 ohms 40 ohms phone 3 mW 75 mW Stereo phone jack
Where 0 dBu=0.775 Vrms and 0 dBV=1 Vrms
■ Analog Output Specifications
Connector Format Data Length Connector Specification
USB USB Audio 1.1 16 bit USB B type
■ Digital Input/Output Specifications
