Appendix
MW10 Owner's Manual
23
Appendix
Specifications
■ Electrical Characteristics
Where 0 dBu = 0.775 Vrms
Output impedance of signal generator: 150 ohms
■ General Specifications
Conditions MIN TYP MAX UNIT
Total Harmonic Distortion
(MIC to ST OUT)
(THD+N) 20 Hz - 20 kHz @ +14 dBu 10k ohms, GAIN controls at
minimum level, all level controls at nominal level
0.1 %
Frequency Response
(CH INPUT 1-9/10, RETURN, 2TR IN to
ST OUT, AUX SEND, C-R OUT, REC
OUT)
20 Hz-20 kHz, nominal output level @ 1 kHz, 10 k ohms, GAIN con-
trols at minimum level (CH INPUT 1-5/6), all level controls at nominal
level
–3 0 1 dB
Hum & Noise
Rs=150 ohms, Gain=Maximum (CH
INPUT 1-2), Hum & Noise are measured
with a -6 dB/octave filter @12.7 kHz;
equivalent to a 20 kHz filter with infinite
dB/octave attenuation.
Equivalent Input Noise (CH INPUT 1-2 MIC) –128 dBu
Residual Output Noise (10 k ohms (ST OUT)) –100 dBu
ST master control at nominal level and all channel LEVEL controls at
minimum level. (ST OUT)
–87
(91 dB S/N)
dBu
All channel AUX controls at minimum level. (AUX SEND)
–85
(89 dB S/N)
dBu
ST master control and one channel LEVEL control at nominal level.
(CH INPUT 1, 2) (ST OUT)
–64
(68 dB S/N)
dBu
Maximum Voltage Gain
1 kHz, 10k ohms
PAN/BAL: panned hard left or hard right.
CH INPUT 1, 2 MIC to CH INSERT OUT, Rs=150 ohms, GAIN con-
trols at maximum level
60 dB
CH INPUT 1-5/6 MIC to ST OUT, Rs=150 ohms, GAIN controls at
maximum level
76 dB
CH INPUT 1-5/6 MIC to REC OUT, Rs=150 ohms, GAIN controls at
maximum level
64.2 dB
CH INPUT 1, 2 MIC to AUX SEND, Rs=150 ohms, GAIN controls at
maximum level, PRE
70 dB
CH INPUT 1, 2 MIC to AUX SEND, Rs=150 ohms, GAIN controls at
maximum level, POST
76 dB
CH INPUT 3/4-5/6 LINE to ST OUT, Rs=150 ohms, GAIN controls at
maximum level
50 dB
CH INPUT 3/4-5/6 LINE to AUX SEND, Rs=150 ohms, GAIN controls
at maximum level, PRE
41 dB
CH INPUT 3/4-5/6 LINE to AUX SEND, Rs=150 ohms, GAIN controls
at maximum level, POST
47 dB
CH INPUT 7/8-9/10 to ST OUT, Rs=150 ohms, GAIN controls at max-
imum level
26 dB
RETURN to ST OUT, Rs=150 ohms 12 dB
2TR IN to ST OUT, Rs=600 ohms 23.8 dB
Crosstalk (1 kHz)
Adjacent inputs –70 dB
input to output –70 dB
Monaural/Stereo CH High Pass Filter
80 Hz 12 dB/octave
Monaural/Stereo CH Equalization
Turn over/roll-off frequency of shelving, 3 dB below maximum
variable level
±15 dB (Max. Variation)
HIGH: 10 kHz (shelving)
MID: 2.5 kHz (peaking)
LOW: 100 Hz (shelving)
Phantom Power
Supplied when Phantom +48 V switch is ON. (XLR-type input jacks)
Monaural/Stereo Input PEAK Indicator
On each channel: red indicator lights if post-EQ signal (on stereo channels, if either post-EQ signal
or post-mic-amp signal) comes within 3 dB of the clipping level.
USB Audio
Input/Output: 44.1/48 kHz
Included Accessories
Power adaptor (PA-10), CD-ROM, USB cable, Owner's manual
Power Consumption
19 W
Dimensions (W × H × D)
251 mm × 65 mm × 290.5 mm
Net Weight
1.8 kg
Temperature Range
Operating temperature: 0 to 40 °C, Storage temperature: -20 to 60 °C
