MG82CX/MG102C
32
1. Measurement condition
1-1 Environment
Normal temperature (5˚C to 40˚C)
Normal humidity (30% to 90%)
1-2 Power supply voltage
The power supply voltage deviation should be within ±10%.
AC adaptor PA-10 should be used.
WC703500 (U, C: 120V), WC703600 (H: 230V), WC703700 (B: 230V), WC703900 (A: 240V),
WC711000 (O: 220V), or WC703800 (K: 220V)
2. Inspections
2-1 Preparation
The load resistances for each output terminals are as follows,
PHONES (L, R) : 40 ohms (
3 W or more)
Others : 10 kohms
2-2 Unless otherwise specifi ed, the controls should be set as follows,
• CH INPUT (CH1, CH2)
GAIN control Maximum (–60/–34 dBu)
COMP control Minimum
80
switch OFF
EQ gain control (HIGH,MID,LOW) Center
EFFECT level control (MG82CX) Minimum
AUX level control (MG102C) Minimum
PAN control L (Turned counterclockwise fully)
CH level control Maximum
• ST CH INPUT (CH3/4, CH5/6)
GAIN control Maximum (–60/–34 dBu)
80
switch OFF
EQ gain control (HIGH, MID, LOW) Center
EFFECT level control (MG82CX) Minimum
AUX level control (MG102C) Minimum
PAN/BAL control L (Turned counterclockwise fully)
CH level control Maximum
• ST CH INPUT (CH7/8, CH9/10 (MG102C))
EQ gain control (HIGH, LOW) Center
EFFECT level control (MG82CX) Minimum
AUX level control (MG102C) Minimum
BAL control L (Turned counterclockwise fully)
CH level control Maximum
• MASTER
RETURN to ST level control Maximum
2TR IN level control Minimum
TO STEREO/TO MONITOR switch OFF (TO STEREO)
MONITOR/PHONES level control Maximum
STEREO level control Maximum
