MG82CX/MG102C
• DIGITAL EFFECT (MG82CX)
DIGITAL EFFECT switch OFF (Light out)
PROGRAM select switch 1
PARAMETER control Minimum
EFFECT RTN level control Minimum
• Others
PHANTOM switch OFF
2-3 Unless otherwise specifi ed, the input signal should be 1 kHz sine wave.
2-4 The signal source impedance should be 150 ohms.
2-5 POWER indicator
Check that the POWER LED lights when the power is turned on.
2-6 Gain
Under 2-2 setting, check that the output level at each output terminal is within the range shown in Tables 2-6-1 to
2-6-6.
* Check that the level difference between channels is 2.0 dB or less.
Table 2-6-1 CH INPUT (CH1, CH2)
INPUT
Input
level
GAIN
control
ST OUT L ST OUT R
EFFECT SEND (MG82CX)
AUX SEND (MG102C)
MONITOR
OUT L
MONITOR
OUT R
①
MIC 1, 2
–72.0 dBu Maximum +1.5 dBu ± 2.0 dB *1 +1.5 dBu ± 2.0 dB *1 +4.5 dBu ± 2.0 dB *2 +18.5 dBu ± 2.0 dB *1 +18.5 dBu ± 2.0 dB *1
②
–28.0 dBu Minimum +1.0 dBu ± 2.0 dB *1
—— ——
PHONE
(LINE)
1, 2
–2.0 dBu Minimum +1.5 dBu ± 2.0 dB *1
—— ——
*1 Set the PAN control to Center.
*2 Set the EFFECT (AUX) level control to Maximum.
Table 2-6-2 CH INPUT (CH1, CH2)
INPUT
Input
level
GAIN
control
INSERT OUT
(1, 2)
REC OUT L REC OUT R
③
MIC 1, 2
–72.0 dBu Maximum –12.0 dBu ± 2.0 dB
——
PHONE
(INSERT)
1
0 dBu
——
–1.3 dBu ± 2.0 dB –1.3 dBu ± 2.0 dB
2
0 dBu
——
–1.3 dBu ± 2.0 dB
—
Table 2-6-3 ST CH INPUT (CH3/4, CH5/6)
INPUT
Input
level
GAIN
control
ST OUT L ST OUT R
EFFECT SEND (MG82CX)
AUX SEND (MG102C)
④
MIC 3/4, 5/6
–72.0 dBu Maximum +1.5 dBu ± 2.0 dB *1 +1.5 dBu ± 2.0 dB *1 +7.0 dBu ± 2.0 dB
⑤
–28.0 dBu Minimum +1.5 dBu ± 2.0 dB *1 +1.5 dBu ± 2.0 dB *1
—
⑥
PHONE
(LINE)
3 L/MONO
5 L/MONO
–46.0 dBu Maximum
+1.5 dBu ± 2.0 dB *1
—
+7.0 dBu ± 2.0 dB
⑦
4 R, 6 R
—
+1.5 dBu ± 2.0 dB *1 +1.0 dBu ± 2.0 dB
*1 Set the PAN control to Center.
