DIMENSIONS
DIMENSIONS
DIMENSION CHART
Unit: mm
Model (Code) PTO shaft dimensions (Type) Mounting face dimensions
MX360 AA6A6
(7HCJ)
4.5
5
72.2
28
60.3
88.5
25.4
-0.021
0
110
+0.054
0
146.08
-0.040
0
21.8
-0.1
0
6.31
+0.058
0
3/8 -24UNF-2B
30
30
146.08
0
-0.040
165.1
127
110
+0.054
0
4 3/8-16UNC2B
DEPTH18
4 5/16-24UNF-2B
DEPTH18
45
45
2 5/16-24UNF-2B
DEPTH18
*1: UNF; Unified fine thread (Unit: in)
*2: UNC; Unified coarse thread (Unit: in)
