4-10
SPEC
GENERAL TORQUE SPECIFICATIONS
GENERAL TORQUE
SPECIFICATIONS
This chart specifies torque for standard fas-
teners with standard I.S.O. pitch threads.
Torque specifications for special components
or assemblies are included in the applicable
sections of this book. To avoid warpage, tight-
en multi fastener assemblies in a crisscross
fashion, in progressive stages, until full torque
is reached. Unless otherwise specifications
call for clean, dry threads. Components should
be at room temperature.
Thread size
Tightening torque
Nm m·kgf ft·lbf
M4 2.0 0.2 1.5
M5 3.0 0.3 2.2
M6 7 0.7 5.2
M7 10 1.0 7.4
M8 15 1.5 11.1
M10 30 3.0 22.1
M12 60 6.0 44.3
