Yamaha MX360 - Adjusting the Governor

2-2
ENG
GOVERNOR
3
2
1
ADJUSTING THE GOVERNOR
1. Remove:
9 Fuel tank
(Refer to “FUEL TANK, CANISTER” in
7HC-F8197-10 chapter 3.)
2. Adjust:
9 Governor
Adjustment steps:
a. Loosen the governor arm bolt 1.
b. Turn the governor arm 2 clockwise
until it stops.
c. Turn the governor shaft 3 clockwise
until it stops.
d. Tighten the governor arm bolt 1.
8 Nm (0.8 m · kgf, 5.8 ft · lbf)
