Yamaha MX360 - Front; Mounting Base

1-4
GEN
INFO
DIMENSIONS
FRONT
Unit: in (mm)
16.46 (418)
7.4 (188)
4.92 (125) 8.13 (206.5)
3.9 (99)
0.63
(16)
2.44
(62)
1.46
(37)
4.02
(102)
2.56
(65)
2 0.43 (11) (HOLE)
2
0.43 (11)
1.06 (27) (SLOT HOLE)
MOUNTING BASE
Unit: in (mm)
41.3 (105)
3.56 (90.5)
2
0.43 (11)
0.63 (16)
0.43 (11)
2
2.56
(65)
1.46
(37)
