Yamaha MX360 - Location of Important Labels

1-3
GEN
INFO
DIMENSIONS
TOP
Unit: in (mm)
LEFT SIDE
Unit: in (mm)
18.19 (462)
6.42 (163)
3.56 (90.5)
7.7 (195.5)
4.06 (103)
19.29 (490)
5.26 (133.5)
2.76(70)
16.81(427)
11.81 (300) 6.38 (162)
