SPEC
MAINTENANCE SPECIFICATIONS
Model name:
MX360
Model code number:
7HCJ
Crankshaft: mm (in)
Big end side clearance “A”
0.20–0.65 (0.008–0.026)
<Limit>
***
Runout “B”
<Limit>
0.02 (0.0008)
Crank pin outside diameter “C”
35.969–35.984 (1.4161–1.4167)
<Limit>
***
Crankshaft free play
0–0.2 (0.000–0.008)
Connecting rod: mm (in)
Small end diameter “A”
20.006–20.020 (0.7876–0.7882)
Oil clearance
0.006–0.025 (0.0002–0.0010)
Big end diameter “B”
***
Big end oil clearance
***
<Limit>
***
Camshaft: mm (in)
Camshaft outside diameter
113.4–113.7 (4.465–4.476)
Camshaft lobe dimensions
***
“A” IN
<Limit>
***
“A” EX
***
<Limit>
***
“B” IN
***
<Limit>
***
“B” EX
***
<Limit>
***
Camshaft journal diameter
15.965–15.990 (0.6285–0.6295)
<Limit>
15.950 (0.628)
