Yamaha MX825 - Page 22

BASIC SERVICE INFORMATION
1-10
1
2
3
4
5
6
7
8
9
10
GENERAL INFORMATION
5. Check:
• Resistance
TIP
The resistance values shown were obtained at the stan-
dard measuring temperature of 20 C (68 F). If the mea-
suring temperature is not 20 C (68 F), the specified
measuring conditions will be shown.
Model 88 Multimeter with tachometer:
YU-A1927
Engine temperature sensor resistance:
9.0 k–11.0 k at 25 C (77 F)
