Yamaha RS VECTOR - Passenger Grips (RST90 PGT); Passenger Grip Warmer Switch (RST90; RST90 PGT)

Control functions
30
RS90P / RS90PLT / RST90PGT
RST90
NOTICE
ECS00180
Make sure that the V-belt is installed se-
curely in the holders.
ESU13302
Passenger grips (RST90PGT)
The passenger grips can be installed in three
different positions to suit the passenger’s
preference.
To change the passenger grip posi-
tion
1. Remove the passenger grip adjusting
knob by turning it counterclockwise.
2. Move the passenger grip to the desired
position.
3. Install the adjusting knob by turning it
clockwise.
WARNING
EWS00780
Make sure that the passenger grip adjust-
ing knobs are securely tightened after
changing the positions of the passenger
grips.
ESU10681
Passenger grip warmer switch
(RST90 / RST90PGT)
The passenger grip warmer switch controls
the electrically heated passenger grips.
1. V-belt holder
1. V-belt holder
1
1. Passenger grip
2. Passenger grip adjusting knob
2
1
