3 Connecting the radio antennas
Connect the supplied radio antenna to the unit.
FM/AM antennas (China model only)
Connect the supplied FM/AM antennas to the unit.
Fix the end of the FM antenna to a wall, and place the AM antenna on a flat surface.
Assembling the AM antenna
Connecting the AM antenna
X
• Unwind only the length of cable needed from the AM antenna unit.
• The wires of the AM antenna have no polarity.
