Connecting the AM antenna
Model For
U.S.A., Canada, Asia, Korea, China, Taiwan, Brazil, General, and Central and South America
Connect the supplied AM antenna to the unit.
Place the AM antenna on a flat surface.
ANTENNA
FMAM
AUDIO 5AUDIO 4
COAXIAL
HDMI
CENTER FRONT
SURROUND BACK
EXTRA SP2
/ZONE 2/BI-AMP
SPEAKERS
PHONO
ZONE OUT
ZONE 2
GND
AUDIO 2
(3 MUSIC)
AUDIO 3
F. PRESENCE
EXTRA SP1
/ZONE 2
SURROUND
NETWORK
HDMI OUT
eARC/ARC
( 2 RADIO )
(4 NET RADIO)
(8 SERVER)
1 2 3 4 5 6 7
(1 MOVIE) (5 STB) (6 GAME)
PRE OUT
FRONT SUBWOOFER
1
2
75
AM antenna
The unit (rear)
Assembling and connecting the AM antenna
NOTE
(
Unwind only the length of cable needed from the AM antenna unit.
(
The wires of the AM antenna have no polarity.
