Yamaha Sniper - Removing the Rear Wheel

CHAS
REAR WHEELAND BRAKE
7-9
1
4
3
2
1
2
1
2
EAS00563
REMOVING THE REAR WHEEL
1. Stand the vehicle on a level surface.
w
Securely support the vehicle so that there is
no danger of it falling over.
NOTE:
Place the vehicle on a suitable stand so that the
rear wheel is elevated.
2. Remove:
9
brake rod adjusting nut
1
9
brake rod
2
9
compression spring
3
9
washer
9
pin
4
NOTE:
Press down on the brake pedal to remove the
pin from the brake rod.
3. Remove:
9
cotter pin
9
brake torque rod nut
1
9
washer
9
brake torque rod bolt
9
brake torque rod
2
4. Loosen:
9
chain puller locknuts (left and right)
1
9
chain puller adjusting nuts (left and right)
2
