1
CHK
ADJ
3-18
3. Remove:
9
oil level plug
1
9
engine oil drain plug
2
(with O-ring)
9
spring
9
oil strainer
4. Drain:
9
engine oil
(completely from the crankcase)
5. Check:
9
oil strainer
Clog
→
Clean.
Damage
→
Replace.
6. Install:
9
oil strainer
9
spring
9
O-ring
9
engine oil drain plug
7. Fill:
9
crankcase
(with the specified amount of the recom-
mended engine oil)
8. Install:
9
oil level plug
9. Start the engine, warm it up for several min-
utes, and then turn it off.
10. Check:
9
engine
(for engine oil leaks)
11. Check:
9
engine oil level
Refer to “CHECKING THE ENGINE OIL
LEVEL”.
CHANGING THE ENGINE OIL
Quantity
Total amount
1.15 L(1.22 US qt, 1.01 Imp gt)
Periodic oil change amount
0.8 L(0.85 US qt, 0.70 Imp gt)
2
EAS00075
CHANGING THE ENGINE OIL
1. Start the engine, warm it up for several min-
utes, and then turn it off.
2. Place a container under the engine oil drain
bolt.
32 Nm (3.2 m•kg, 23 ft•lb)
To Next Page
