HOW TO USE THIS MANUAL
CONSTRUCTION OF THIS MANUAL
This manual consists of chapters for the main categories of subjects. (See “Illustrated symbols”)
1st title
1
:This is a chapter with its symbol on the upper right of each page.
2nd title
2
:This title appears on the upper of each page on the left of the chapter symbol. (For the
chapter “Periodic inspection and adjustment” the 3 rd title appears.)
3rd title
3
:This is a final title.
MANUALFORMAT
All of the procedures in this manual are organized in a sequential, step - by - step format. The informa-
tion has been compiled to provide the mechanic with a easy to read, handy reference that contains
comprehensive explanations of all disassembly, repair, assembly, and inspections.
Aset of particularly important procedure
4
is placed between a line of mark “
✭
” or “
✬
” with each pro-
cedure preceded by “
8
”.
IMPORTANT FEATURES
8
Data and a special tool are framed in a box preceded by a relevant symbol
5
.
8
An encircled numeral
6
indicates a part name, and an encircled alphabetical letter date or an align-
ment mark
7
, the others being indicated by an alphabetical letter in a box
8
.
8
Acondition of a faulty component will precede an arrow symbol and the course of action required the
symbol
9
.
EXPLODED DIAGRAM
Each chapter provides exploded diagrams before each disassembly section for ease in identifying cor-
rect disassembly and assembly procedures.
